9690-Monocular Microscope

9690-Monocular Microscope

Share the Product

Newly introduced series of educational Microscope which extends top quality optics and uncompromising performance for educational and routine research work.

 DIN Standard Objectives:

All the objectives are parcentered and parfocal minimize focusing procedures.



 Features:

  1. Mechanical tube length 160 mm.
  2. 45º inclined with 360 degree rotatable binocular head.
  3. Co-axial built in Mechanical stage 125 x 150 mm with fine vernier graduation, designed with convenient coaxial adjustment on ball bearing guide ways for smooth slide manipulation through 50 x 70 mm.
  4. Dust proof quadruple/quintruple ball bearing revolving nose piece with positive click stops.
  5. Co-axial coarse & fine focusing adjustment knobs.. Fine motion, graduated to .002 mm.
  6. Substage Abbe type N.A. 1.25 condenser focusable with rack & pinion, continuously variable iris diaphragm with built in swing out filter holder.
  7. Steple Grey, chemical resistant, back-on finish.
  8. Exclusive preset focus lock prevents damage to valuable slides and objectives.
  9. Heavy rectangular sturdy base, with built-in illumination 6V – 20W halogen lamp.
  10. Complete parts of the microscope are pressure Die-casted.
  11. With dust cover packed in Styrofoam packing.
