12780-MICROPROCESSOR PHOTO COLORIMETER

,

12780-MICROPROCESSOR PHOTO COLORIMETER

Share the Product

Features:

  • Highly Accurate & Stable
  • Range 400 to 700 nm
  • 16 X 2 Line Alphanumeric LCD Display
  • Printer Attachment Facility
  • Storage For 100 Samples
  • Soft Touch Membrane Keys

Specifications:



WAVE LENGTH RANGE 400 to 700 nm
RESOLUTION 1%T, 0.01Abs., 0.01 Conc., 0.01 K Factor
%TRANSMISSION 0 – 100% T
ABSORBANCE 0 – 1.99A
CONCENTRATION 0 – 19999
K FACTOR 1 – 19999
PHOTO DETECTOR Silicon Photodiode / Photo Cell
DISPLAY 16×2 line alphanumeric LCD display with  backlit
KEYBOARD 8 Keys, soft touch membrane keys
DATA STORAGE Up to 100 Samples
LIGHT SOURCE 6.8V, 0.3Amp. Tungsten lamp
SAMPLE SYSTEM 10mm path length matched glass test tubes
FILTERS 400, 420, 480, 500, 520, 540, 620, 680nm
PRINTER INTERFACE Centronics parallel Printer interface for any dot matrix printer
RS232 INTERFACE Available (On Request)
WEIGHT 2.5 Kg.
POWER SUPPLY 230V AC ±10%, 50Hz. with in-built Stabilizer
ACCESSORIES Matched Test Tube Set of 5, Operation Manual, Dust Cover, Spare Lamp
Part No. Description
12780

MICROPROCESSOR PHOTO COLORIMETER
